AFL introduces the new FSM12S Fixed V-groove and FSM70S Core Alignment Splicers

The Fujikura 12S fusion splicer is the smallest, lightest, and most portable splicer in the world. The ruggedized chassis features shock, dust and moisture protection while the two camera observation system provides for accurate fiber alignment and loss estimation calculations.

Weighing less than two pounds and having a footprint of approximately 6" x 5", the 12S provides users with an unprecedented level of flexibility for the most challenging splicing applications. The functional transit case also serves as a workstation when needed. The large 4.5" scratch resistant monitor is viewable in direct sunlight.  Software updates are accomplished via the internet, allowing users to quickly and conveniently update their software as new splice programs become available.  The Fujikura 12S is also fully compatible with the FuseConnect line of fusion installable connectors.  To cap off all these great features, a long life battery and extended life electrodes keep you up and running when you need it most.

The Fujikura 70S is a fully ruggedized, core alignment fusion splicer, providing consistent, low loss, splice performance. The new design streamlines the steps required to complete splices, resulting in greater productivity. “Configurable automation” features allow you to customize the operation of the machine to best suit your particular splicing technique and process. A new programmable “automatic wind protector” closes and begins the splicing process after clamping the fibers in position or pressing the “set” button. Once the splice is completed, not only is the wind protector opened, but one of the sheath clamps, you decide which, is automatically raised making removal of the fibers fast and easy! Similarly, the "clamshell" design of the tube heater clamps the splice splice protection sleeve and applies heat from both sides which results in a reduced shrink time of just 14 seconds.
