Fujikura 70S Fusion Splicer
The Fujikura 70S is the world’s fastest and most robust core alignment fusion splicer. Incorporating the proven ruggedized features pioneered by Fujikura, the 70S has added automated and enhanced user control features to increase splicing efficiency. A user programmable, automated wind protector expedites the splicing process by automatically closing to initiate the splice process, and opening upon splice completion. Fully programmable “auto open sheath clamps” open one sheath clamp, after the tensile test, to prepare the fiber for removal. A new automated “clamshell design” tube heater applies heat to both sides of the splice protection sleeve resulting in a 14-second shrink time. The result is a total splice process time of approximately 21 seconds! Ruggedness and durability are greatly enhance by a mirror-less optical system and “severe-impact resistant” monitor. Battery capacity is now 200 splices/shrinks. An innovative transit case doubles as a built-in or mobile workstation and makes splicing easier than ever before.
FSM-70S includes – ADC-18 AC Adapter, ACC-14 AC Cord, ELCT2-20A Spare Electrodes (pair), S70A Sheath Clamp, USB Cable, Alcohol Pot, Screw Driver, Splicer Carrying Strap, Quick Reference Guide, Video Instruction Manual and CC30 Transit Case with Carrying Strap
Features
- Automated and programmable wind protector
- 14-second automated tube heater
- Fully ruggedized for shock, dust and moisture
- Li-Ion battery with 200 splices/shrinks per charge
- 5 mm cleave length for splice on connector or small package needs
- Sheath clamp or fiber holder operation
- On-board training and support videos
- Internet software upgrades
- Multi-function transit case with integrated workstation
Also available are the KIT (with Cleaver ) – Part # S015590 and the KIT with Cleaver, Battery and Cord – # S015591
Call or email for lowest price on kits – esales@tamge.com or (207) 221-3154
- Model: 70S Fusion Splicer
- Applicable Fibers: Single-mode (G.652 & G .657), Multimode (G.651), DS (G.653), NZDS (G.655)
- Cladding Diameter: 80 μm to 150 μm
- Coating Diameter: 100 μm to 1,000 μm
- Fiber Cleave Length: 5 to 16 mm
- Typical Average Splice Loss: 0.02 dB with SM, 0.01 dB with MM, 0.04 dB with DS, 0.04 dB with NZDS, measured by cut-back method relevant to ITU-T and IEC standards
- Splicing Time: SM FAST mode — 7 seconds; SM AUTO mode — 12 seconds; AUTO mode — 15 seconds
- Arc Calibration Method: Automatic, real-time and by using results of previous splice when in AUTO mode, manual arc calibration function available
- Splicing Modes: 100 preset and user programmable modes
- Splice Loss Estimate: Based upon dual camera core alignment data
- Storage of Splice Result: Last 2,000 results to be stored in the internal memory
- Fiber Display: X or Y, or both X and Y simultaneously. Front or rear monitor display options with automated image orientation
- Magnification: 300X for single X or Y view, or 160X for X and Y view
- Viewing Method: Dual cameras with 4.73 inch TFT color LCD monitor
- Operating Condition: 0 to 5,000 m above sea level, 0 to 95%RH and -10 to 50°C respectively
- Mechanical Proof Test: 1.96 to 2.25N
- Tube Heater: Built-in tube heater with 30 heating modes; auto-start function
- Tube Heating Time: Typical 14 seconds with FP-03 sleeve, 17 seconds with FP3 (40), 5-16 seconds with Fujikura micro sleeves
- Protection Sleeve Length: 60 mm, 40 mm, micro, Splice/Heat Cycles with Battery, Typical 200 cycles with power save functions activated
- Splice/Heat Cycles with Battery: Typical 200 cycles with power save functions activated
- Power Supply: Auto voltage selection from 100 to 240 V AC or 10 to 15 V DC with ADC-18, 14.8 V DC with BTR-09 battery
- Terminals: USB 1.1 (USB-B type) for PC communication. Mini-DIN (6-pin) for HJS-02/03 and SH-8 tube heater
- Wind Protection: Maximum wind velocity of 15 m/s. (34 mph)
- Dimensions: 146 W x 159 D x 150 H (mm) / 5.75 W x 6.25 D x 5.9 H (inches)
- Weight: 2.5 kg (5.5 lbs) with AC adapter ADC-18; 2.7 kg (5.95 lbs) with BTR-09 battery
The Fujikura 70S is also fully compatible with the AFL FuseConnect line of splice-on connectors. The sheath clamps are easily removed for FuseConnect installations or for use with fiber holders for standard splicing applications. Ask me for the pdf for the FuseConnect connectors.
